Series R1800 Heavy Duty Gravity Roller
Application area
R1800 series heavy duty gravity roller is suitable for unit goods handling such as transport of carboards, containers, barrels, tires or pallets. Suited for cost-efficient implementation of gravity or push conveyors. The roller has a large range diameter of pipe and shaft for transport of light, medium and heavy goods. Steel bearing housing for use in a very board temperature range from −30 to +80 °C.
High reliability
The precision ball bearing is secured in the steel pressed bearing housing. The bearing is tight and durable. Able to withstand greater axial forces than a plastic bearing unit.
Lateral loading
The bearing housing bearing is pressed into the tube and the tube ends are rounded, thereby allowing materials to be easily moved on from the side.
High load capacity
Full range diameter of roller tube and shaft, steel bearing housing ensure the roller is cable of being used in many arduous environment including pallet handling.
Technical data
General technical data | |
Max. load capacity | 600 KGS |
Max. conveyor speed | 50 m/min |
Temperature range | −30 to +80 °C |
Material | |
Tube | Carbon steel, stainless steel, aluminum |
Shaft | Antirust oil coated steel, Zinc-plated steel, Stainless steel |
Bearing housing | Zinc-plated steel, stainless steel |
Bearing | Precision ball bearing |
Design versions | |
Surface treatment | Zinc-plated, chrome-plated |
Tube sleeves | PP sleeve, PU sleeve |
Lagging | Rubber, PU |
Diagram of R1800 Heavy Duty Gravity Conveyor Roller
Dimension of series R1800 with spring loaded installation
Tube Material | D × T | Shaft | E | L |
Steel, stainless steel, aluminum | 25×1.0 | Φ12 | E=W+7 | L=W+31 |
Steel, stainless steel, aluminum | 32×1.2 | Φ12 | E=W+9 | L=W+31 |
Steel, stainless steel, aluminum | 38×1.2 | Φ12 | E=W+10 | L=W+32 |
Steel, stainless steel, aluminum | 50×1.5 | Φ12 | E=W+10 | L=W+32 |
Steel, stainless steel, aluminum | 60×2.0 | Φ12/Φ15 | E=W+10 | L=W+32 |
Steel, stainless steel, aluminum | 76×3.0 | Φ20 | E=W+10 | L=W+40 |
Steel | 80×3.0 | Φ20 | E=W+10 | L=W+40 |
Steel | 89×3.0 | Φ20 | E=W+10 | L=W+40 |
Load capacity of series R1800 with loose installation
The load capacity chart shows the static load capacity of the roller for a uniformly distributed load refers to a temperature range of −30 to +80 °C.
Valid for the following shaft designs: spring-loaded shaft or flatted shaft.
Dimensions of series R1800 with female threaded installation
Tube Material | D × T | Shaft | E | L |
Steel, stainless steel, aluminum | 25×1.0 | Φ12 | E=W+7 | L=W+8 |
Steel, stainless steel, aluminum | 32×1.2 | Φ12 | E=W+9 | L=W+10 |
Steel, stainless steel, aluminum | 38×1.2 | Φ12 | E=W+10 | L=W+11 |
Steel, stainless steel, aluminum | 50×1.5 | Φ12 | E=W+10 | L=W+11 |
Steel, stainless steel, aluminum | 60×2.0 | Φ12/Φ15 | E=W+10 | L=W+11 |
Steel, stainless steel, aluminum | 76×3.0 | Φ20 | E=W+10 | L=W+12 |
Steel | 80×3.0 | Φ20 | E=W+10 | L=W+12 |
Steel | 89×3.0 | Φ20 | E=W+10 | L=W+12 |
Load capacity of series R1800 with screw-connected installation
The load capacity chart shows the static load capacity of the roller for a uniformly distributed load refers to a temperature range of −30 to +80 °C.
Valid for the following shaft designs: female thread or male thread.
